ABB SPA - ABB1SAL220348R9901 MC1A301ATM MINICONTATTORE AC 3NA A VITE - 1SAL220348R9901

KopierenKopieren

Melden Sie sich an, um Preise und Verfügbarkeit anzuzeigen

Haupteigenschaften

  • Bemessungssteuerspeisespannung AC 50 Hz - 208...220 V

  • Spannungsart zur Betätigung - AC

  • Bemessungsbetriebsleistung bei AC-3, 400 V - 4 kW

  • Bemessungsbetriebsstrom Ie bei AC-1, 400 V - 20 A

  • Bemessungsbetriebsleistung bei AC-4, 400 V - 4 kW

Packung

  • 1 ST

Grüne Produktbewertung

Grüne Bewertung

CO2-Fußabdruck von Produkten

72 kg CO₂-Äquivalent

Sonepar-Schätzung

EAN

4013614541483

Artikelnummer

ABB1SAL220348R9901

Herstellernummer

1SAL220348R9901

Hersteller

ABB

Bemessungssteuerspeisespannung AC 50 Hz:

208...220 V

Spannungsart zur Betätigung:

AC

Bemessungsbetriebsleistung bei AC-3, 400 V:

4 kW

Bemessungsbetriebsstrom Ie bei AC-1, 400 V:

20 A

Bemessungsbetriebsleistung bei AC-4, 400 V:

4 kW

Geeignet für Reiheneinbau:

nein

Anschlussart Hauptstromkreis:

Schraubanschluss

Bemessungsbetriebsleistung NEMA:

2.24 kW

Anzahl der Schließer als Hauptkontakte:

3

Bemessungssteuerspeisespannung AC 60 Hz:

208...220 V

Anzahl der Hilfskontakte als Schließer:

0

Bemessungsbetriebsstrom Ie bei AC-3, 400 V:

9 A

Anzahl der Öffner als Hauptkontakte:

0

Anzahl der Hilfskontakte als Öffner:

1

Bemessungsbetriebsstrom Ie bei AC-4, 400 V:

9 A

Betriebsspannung AC 50 Hz:

440...690 V

Betriebsspannung AC 60 Hz:

440...690 V

Breite:

45 mm

Höhe:

48 mm

Tiefe:

56 mm

The MC1A301ATM mini contactor is a dimension optimized 3 pole contactor with 1 NC auxiliary contact and screw terminals. This device is a great solution when high performances are needed but the space is limited. Mini contactors are used in residential buldings, commercial buildings and industrial applications for the control of single or three-phase loads up to 4 kW (AC-3) and 20 A / 690 V (AC-1) or switching of control signals. The product is suitable for wall or rail mounting.
